EN 10028-3 GRADE P355NH

EN 10028-3 GRADE P355NH PLATES

P355NH Steel Plates, EN 10028-3 Steel plate, EN 10025–6 P355NH Pressure Vessel Plates, 1.0565 Steel Plate, EN 10028-3 Grade P355NH Normalized Steel Plates Exporters, Suppliers and Stockists in India.

Kailash Steel and Engineering Co is one of the renowned manufacturers of EN 10028-3 Grade P355NH Plates, which have a remarkable multi-circular segment particle titanium covering.

Being the well-distinguished companies in the market, we are into offering these products. We provide a wide range of EN 10028-3 Gr. P355NH Plates, which are manufactured using qualitative raw materials, and are used in diverse industrial applications, available in different sizes. We are the exporters of Grade P355NH EN 10028-3 Plates and prepare them in various designs as per the specifications of our clients. Backed by the team of skilled professionals, we are highly devoted towards offering a wide range of excellent quality these plates. Due to the molybdenum content of 3 % – 4%, EN 10028-3 Grade P355NH Plates are more resistant to general corrosion and pitting/crevice corrosion. We have marked a distinct and dynamic position in the market by trading and supplying a high quality array of these plates, which is highly utilized in the gas and oil industry. We provide the same to our esteemed clients in various specifications of length and thickness, which is highly resistant to corrosion.



The company has an illustrious clientele that increases to market in several countries, and is recognized as an innovator in the market when it comes to their products and finishing excellent quality. We manufacture these plates for usage and application in different industries, which are rigidly designed by using the graded stainless steel and advanced tools.

Equivalent Grades of EN 10028-3 P355NH (1.0565) Steel Plate

EU EN USA
Germany
DIN,WNr
France
AFNOR
England
BS
Italy
UNI
P355NH A662Gr.C WStE355 A510AP 224Gr.490 FeE355-2

P355NH EN 10028-3 – Chemical Composition

C Si Mn Ni P S Cr Mo V N Nb Ti Al Cu
max 0.18 max 0.5 1.1 – 1.7 max 0.5 max 0.025 max 0.015 max 0.3 max 0.08 max 0.1 max 0.012 max 0.05 max 0.03 max 0.02 max 0.3 Nb+Ti+V < 0.12

EN 10028-3 Grade P355NH Mechanical Property

Grade Thickness Yield Tensilmie Elongation Impact Energy(KV J) min
P355NH mm Min Mpa Mpa Min  % -20° +20°
≤ 16 355 490-630 22 47 55 63
16> to ≤35 355 490-630 22 47 55 63
35> to ≤50 345 490-630 22 47 55 63
50> to ≤70 325 490-630 22 47 55 63
70> to ≤100 315 470-610 21 47 55 63
100> to ≤150 295 450-590 21 47 55 63
×
